To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test
procedures require power to be connected. Discharge capacitor through a resistor before attempting to service.
Ensure all ground wires are connected before certifying unit as repaired and/or operational.
WARNING!
Disassembly
26 ©2012 Viking Preferred Service
Front
Levelling
Legs
Drain
Motor
Machine
Control
Board
Fill
Valve
Wash
Temp
Sensor
Flow thru
Heater
Parts Location - Base Unit
Pump/
Motor
Motor
control
board
Blower
Motor
Diverter
valve
Rear Levelling Leg
To Next Page
