To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test
procedures require power to be connected. Discharge capacitor through a resistor before attempting to service.
Ensure all ground wires are connected before certifying unit as repaired and/or operational.
WARNING!
Troubleshooting
©2012 Viking Preferred Service 43
Air is pulled from dishwasher interior by blower during the dry cycle, in conjunction with
the energizing of the vent wax motor. The moist air is exhausted through the blower
out the front kickplate grill There is no heater element in the drying system, drying is
accomplished as explained on the previous page.
