Wiring and Schematics
Component information–Electrical Specifications
Component Name Volts Ohms Amps Watts Input/Load
Drain motor 120-Volts AC 14-15 ohm 45 Load
Wash diverter 120-Volts AC 27,000 ohms (27k ohms) 0.01 4 Load
Circulation motor 120 - 155-Volts AC 15.0 ohm-Three-phase 1.2 150 Load
Water heater 120-Volts AC 10.5 ohm 11.4 1400 Load
Water temp sensor 12-Volts DC 46k - 49k ohm @ Ambiant N/A N/A Input
Fill valve 120-Volts AC 1000 ohms (1k ohm) 0.12 14.4 Load
Drying motor 12-Volts DC 1750 ohms (17.5k ohms) 0.7 8.4 Load
Moisture sensor 12-Volts DC *180,000 ohms (180k ohms) N/A N/A Input
Detergent dispenser 12-Volts DC N/A 1.2 N/A Load
Active vent wax motor 12-Volts DC N/A 1.2 N/A Load
Dryer heating element 1120-Volts AC 133.3 ohm 0.9 115 Load
Water level sensor 5-Volts DC Input
* When sensor is dry and no corrosion.
