Troubleshooting
©2013 Viking Preferred Service 13
Parts Location – Control Board
Model Serial Description
P13 - Second
Board
P9 - Model
Wire Color Connections
Single Oven Status Select
VESO 5271 5272 N/A Pro - Single - Premiere - 27" PE070734 N/A White Model 14 - Pins 1, 3 and 6
VESO 5301 5302 N/A Pro - Single - Premiere - 30" PE070734 N/A White Model 14 - Pins 1, 3 and 6
Model Serial Description
P13 - Second
Board
P9 - Model
Select
P9 Model
Select
Wire Color Connections
Double Oven Status Select
VEDO 5271 5272 N/A Pro - Double - Premiere - 27" PE070734 N/A PE070795 Yellow Model 3 - Pins 3 , 6
VEDO 5301 5302 N/A Pro - Double - Premiere - 30" PE070734 N/A PE070763 White Model 1 - Pins 5 , 6
