20 - ENGLISH
1 2 3 4
6
7 8
ON
4.3.8
Press the front button within 15 sec-
onds. The LED turns red.
Warning!
If the button is not pressed within 15
seconds, the LED turns red and the
system switches to the “Reprogram
reader code and MASTER smart cards”
procedure.
4.3.7
Place dip-switch 2, on the reader being
synchronised, in the ON position.
The LED lights up yellow.
4.3.4
The LED switches off to signal that the
smart card code has been copied, and
the reader/programmer synchronised.
4.3.5
Remove the MASTER smart card.
The LED turns green again.
4.3.6
To exit the procedure, place dip-switch 2
in the OFF position.
The LED switches off.
1 2 3 4
6
7 8
ON
Synchronising an already-initialised reader
