Vimar Plana Instruction Handbook

ENGLISH - 21
4.3.9
Insert the MASTER smart card into the
reader being synchronised.
MASTER
card
MASTER
card
If the LED blinks red it means the key
was not recognised.
Remove the smart card and insert the
correct one.
4.3.10
If the MASTER smart card is recognised,
the LED switches off.
4.3.12
Insert a MASTER smart card, already
programmed by the synchronising
reader/programmer, into the reader being
synchronised.
Synchronising
card
Synchronising
card
4.3.13
The LED switches off to signal that the
smart card code has been copied, and
the reader/programmer synchronised.
4.3.11
Remove the MASTER smart card.
The LED blinks green.
