Manual VIPA System 200V Chapter 2 Analog input modules
HB97E - SM-AIO - Rev. 12/32 2-17
The assignment of a function-no. to a certain channel happens during
parameterization. The function-no. 00h does not influence the function-no.
stored in the permanent parameterization data.
Assigning FFh deactivates the according channel.
No. Function Measurement range / representation Conn.
00h Does not affect permanently stored configuration data
01h Pt100 in 2wire mode
-200
°C ... +850°C /
in units of 1/10°C, two’s complement
(3)
02h Pt1000 in 2wire mode
-200
°C ... +850°C /
in units of 1/10°C, two’s complement
(3)
03h NI100 in 2wire mode
-60
°C ... +250°C /
in units of 1/10°C, two’s complement
(3)
04h NI1000 in 2wire mode
-60
°C ... +250°C /
in units of 1/10°C, two’s complement
(3)
05h Resistance measurement
60Ohm 2wire
-
/
60Ω= final value (32767)
(3)
06h Resistance measurement
600Ohm 2wire
-
/
600Ω = final value (32767)
(3)
07h Resistance measurement
3000Ohm 2wire
-
/
3000Ω = final value (32767)
(3)
08h Resistance measurement
6000Ohm 2wire
- /
6000
Ω = final value (32767)
(3)
09h Pt100 via
4wire connection
-200
°C ... +850°C /
in units of 1/10°C, two’s complement
(4)
0Ah Pt1000 via
4wire connection
-200
°C ... +850°C /
in units of 1/10°C, two’s complement
(4)
0Bh NI100 via
4wire connection
-60
°C ... +250°C /
in units of 1/10°C, two’s complement
(4)
0Ch NI1000 via
4wire connection
-60
°C ... +250°C /
in units of 1/10°C, two’s complement
(4)
0Dh Resistance measurement
60Ohm 4wire
-
/
60Ω= final value (32767)
(4)
0Eh Resistance measurement
600Ohm 4wire
-
/
600Ω= final value (32767)
(4)
0Fh Resistance measurement
3000Ohm 4wire
-
/
3000Ω = final value (32767)
(4)
10h Thermocouple type J,
1)
externally compensated
-210
°C ... 1200°C /
in units of 1/10°C, two’s complement
(2)
11h
Thermocouple type K,
1)
externally compensated
-270
°C . . +1372°C /
in units of 1/10°C, two’s complement
(2)
12h
Thermocouple type N,
1)
externally compensated
-270
°C . . +1300°C /
in units of 1/10°C, two’s complement
(2)
13h
Thermocouple type R,
1)
externally compensated
-50
°C . . +1769°C /
in units of 1/10°C, two’s complement
(2)
14h
Thermocouple type T,
1)
externally compensated
-270
°C . . +400°C /
in units of 1/10°C, two’s complement
(2)
15h
Thermocouple type S,
1)
externally compensated
-50
°C . . +1769°C /
in units of 1/10°C, two’s complement
(2)
16h
Thermocouple type E,
1)
externally compensated
-270
°C . . +1000°C /
in units of 1/10°C, two’s complement
(2)
18h
Thermocouple type J,
2)
internally compensated
-210
°C . . +1200°C /
in units of 1/10°C, two’s complement
(2)
continued ...
Function-no.
assignment
