VIPA 238-2BC00 - Page 42

Chapter 2 Analog input modules Manual VIPA System 200V
2-18 HB97E - SM-AIO - Rev. 12/32
… continue
No. Function Measurement range / representation Conn.
19h Thermocouple type K,
2)
internally compensated
-270
°C . . +1372°C /
in units of 1/10°C, two’s complement
(2)
1Ah Thermocouple type N,
2)
internally compensated
-270
°C . . +1300°C /
in units of 1/10°C, two’s complement
(2)
1Bh Thermocouple type R,
2)
internally compensated
-50
°C . . +1769°C /
in units of 1/10°C, two’s complement
(2)
1Ch Thermocouple type T,
2)
internally compensated
-270
°C .. +400°C /
in units of 1/10°C, two’s complement
(2)
1Dh Thermocouple type S,
2)
internally compensated
-50
°C .. +1769°C /
in units of 1/10°C, two’s complement
(2)
1Eh Thermocouple type E,
2)
internally compensated
-270
°C .. +1000°C /
in units of 1/10°C, two’s complement
(2)
27h
Voltage
±50mV
Siemens S7 format
(two’s complement)
±58.79mV /
58.79mV = max. value before over range (32511)
-50...50mV= nominal range (-27648...27648)
-58.79mV = min. value before under range (-32512)
(1)
28h
Voltage
±10V
Siemens S7 format
(two’s complement)
±11.76V /
11.76V= max. value before over range (32511)
-10...10V= nominal range (-27648...27648)
-11.76V= min. value before under range (-32512)
(1)
29h
Voltage
±4V
Siemens S7 format
(two’s complement)
±4.70V /
4.70V = max. value before over range (32511)
-4...4V = rated range (-27648...27648)
-4.70V = min. value before under range (-32512)
(1)
2Ah
Voltage
±400mV
Siemens S7 format
(two’s complement)
±470mV /
470mV = max. value before over range (32511)
-400...400mV = rated range (-27648...27648)
-470mV = min. value before under range (-32512)
(1)
2Bh
Voltage
±10V
Siemens S5 format
(value and sign)
±12.50V /
12.50V = max. value before over range (20480)
-10...10V = rated range (-16384...16384)
-12.50V = min. value before under range (-20480)
(1)
2Ch
Current
±20mA
Siemens S7 format
(two’s complement)
±23.52mA /
23.52mA = max. value before over range (32511)
-20...20mA = rated value (-27648...27648)
-23.52mA = min. value before under range (-32512)
(1)
2Dh Current 4...20mA
Siemens S7 format
(two’s complement)
1.185 .. +22.81mA /
22.81mA = max. value before over range (32511)
4...20mA = rated range (0...27648)
1.185 mA = min. value before under range (-4864)
(1)
2Eh Current 4...20mA
Siemens S5 format
(value and sign)
0.8 .. +24.00mA /
24.00mA = max. value before over range (20480)
4 .. 20mA = rated range (0...16384)
0.8mA = min. value before under range (-3277)
(1)
2Fh
Current
±20mA
Siemens S5 format
(value and sign)
±25.00mA /
25.00mA = max. value before over range (20480)
-20...20mA = rated value (-16384...16384)
-25.00mA = min. value before under range (-20480)
(1)
continued ...
