Manual VIPA System 200V Chapter 2 Analog input modules
HB97E - SM-AIO - Rev. 12/32 2-19
… continue
No. Function Measurement range / representation Conn.
32h Resistance measurement
6000
Ω 4wire
- /
6000Ω= final value (32767)
(4)
33h Resistance measurement
6000
Ω 4wire
- /
6000Ω= final value (6000)
(4)
35h Resistance measurement
60
Ω 2wire
- /
60Ω= final value (6000)
(3)
36h Resistance measurement
600
Ω 2wire
- /
600Ω = final value (6000)
(3)
37h Resistance measurement
3000
Ω 2wire
- /
3000Ω = final value (30000)
(3)
38h Resistance measurement
6000
Ω 2wire
- /
6000Ω = final value (6000)
(3)
3Ah
Current
±20mA
Siemens S5 format
two’s complement
±25.00mA /
25.00mA = max. value before over range (20480)
-20...20mA = nominal range (-16384...16384)
-25.00mA = min. value before under range (-20480)
(1)
3Bh
Voltage
±10V
Siemens S5 format
two’s complement
±12.50V /
12.50V = max. value before over range (20480)
-10...10V = nominal range (-16384...16384)
-12.50V = min. value before under range (-20480)
(1)
3Dh Resistance measurement
60
Ω 4wire
-
/
60Ω= final value (6000)
(4)
3Eh Resistance measurement
600
Ω 4wire
-
/
600Ω= final value (6000)
(4)
3Fh Resistance measurement
3000
Ω 4wire
-
/
3000Ω = final value (30000)
(4)
57h
Voltage
±50mV
two’s complement
±58.79mV /
58.79mV = max. value before over range (5879)
-50...50mV = rated range (-5000...5000)
-58.79V = min. value before under range (-5879)
(1)
58h
Voltage
±10V
two’s complement
±11.76V /
11.76V = max. value before over range (11760)
-10...10V = rated range (-10000...10000)
-11.76V = min. value before under range (-11760)
(1)
59h
Voltage
±4V
two’s complement
±4.70V /
4.70V = max. value before over range (4700)
-4...4V = rated range (-4000...4000)
-4.70V = min. value before under range (-4700)
(1)
5Ah
Voltage
±400mV
two’s complement
±470mV /
470mV = max. value before over range (4700)
-400...400mV = rated range (-4000...4000)
-470mV = min. value before under range (-4700)
(1)
5Ch
Current
±20mA
two’s complement
±23.51mA /
23.51mA = max. value before over range (23510)
-20...20mA = rated value (-20000...20000)
-23.51mA = min. value before under range (-23510)
(1)
5Dh Current 4...20mA
two’s complement
1.185 .. +22.81mA
/
22.81mA = max. value before over range (18810)
4...20mA = rated range (0...16000)
1.185mA = min. value before under range (-2815)
(1)
62h Cu50
2wire
-50°C ... +150
°C /
in units of 1/10°C, two’s complement
(3)
6Ah Cu50
4wire
-50°C ... +150
°C /
in units of 1/10°C, two’s complement
(4)
continued ...
