Chapter 2 Analog input modules Manual VIPA System 200V
2-20 HB97E - SM-AIO - Rev. 12/32
… continue
No. Function Measurement range / representation Conn.
91h PTC KTY81-110
3)
990-1010
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
92h PTC KTY81-120
3)
980-1020
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
93h PTC KTY81-121
3)
980-1000
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
94h PTC KTY81-122
3)
1000-1020
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
95h PTC KTY81-150
3)
950-1050
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
96h PTC KTY81-151
3)
950-1000
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
97h PTC KTY81-152
3)
1000-1050
Ω
Two-wire connection
200
°C = max. value before over range (2000)
-55 ... 150
°C = nominal range (-550... 1500)
-100
°C = min. value before under range (-1000)
Values in 0.1
°C
(3)
FFh Channel not active (turned off)
1)
The compensation of the neutralization must be implemented externally
2)
The compensation for the neutralization is implemented internally by including the temperature of the front plug. The
thermal conductors have to be connected directly to the front plug, and where necessary these must be extended by
means of thermo element extension cables
3)
This function is available starting with firmware version 143 of the module.
Note!
The module is preset to the range "±10V voltage" at S7 format.
