At a pending diagnostic the CPU interrupts the user application and
jumps to the OB 82 for diagnostic
incoming
. This OB allows you with an
according programming to monitor detailed diagnostic information via
the SFCs 51 or 59 and to react to it. After the execution of the OB 82
the user application processing is continued. The diagnostic data is
consistent until leaving the OB 82. After error correction automatically
a diagnostic
going
occurs if the diagnostic interrupt release is still active.
In the following the record sets for diagnostic
incoming
and diagnostic
going
are specified.
Record set 0 - diagnostic
incoming
Byte Bit 7 ... 0
0
n Bit 0: set at module failure
n Bit 1: 0 (fix)
n Bit 2: set at external error
n Bit 3: set at channel error
n Bit 4: set at external auxiliary supply missing
n Bit 6 ... 5: reserved
n Bit 7: set at error in parametrization
1
n Bit 3 ... 0: Module class
–
0101b analog module
n Bit 4: Channel information available
n Bit 7 ... 5: reserved
2 00h (fix)
3 00h (fix)
After error correction automatically a diagnostic
going
occurs if the diag-
nostic interrupt release is still active.
Record set 0 - diagnostic
outgoing
Byte Bit 7 ... 0
0 00h (fix)
1
n Bit 3 ... 0: Module class
–
0101b analog module
n Bit 4: Channel information available
n Bit 7 ... 5: reserved
2 00h (fix)
3 00h (fix)
Record sets
VIPA System 300S Deployment I/O periphery
Analog part - Diagnostic functions
HB140 | CPU | 314-6CF03 | GB | 16-43 143
