Record set 1 - channel specific diagnostic
incoming
(Byte 0 ... 14)
Byte Bit 7 ... 0
1...3
Content record set 0 Ä ‘Record set 0 - diagnostic
incoming
’
on page 143
4
n Bit 6 ... 0: Channel type (here 74h)
–
70h: Digital input
– 71h: Analog input
– 72h: Digital output
– 73h: Analog output
– 74h: Analog input/output
n Bit 7: 0 (fix)
5 Number of diagnostic bits per channel (here 08h)
6 Number of channels of a module (here 07h)
7
n Bit 0: Channel error channel 0
n Bit 1: Channel error channel 1
n Bit 2: Channel error channel 2
n Bit 3: Channel error channel 3
n Bit 4: Channel error channel 4
n Bit 5: Channel error channel 5
n Bit 6: Channel error channel 6
n Bit 7: 0 (fix)
8
n Bit 0: Parametrization error channel 0
n Bit 1: 0 (fix)
n Bit 2: 0 (fix)
n Bit 3: 0 (fix)
n Bit 4: Wire break channel 0
n Bit 5: 0 (fix)
n Bit 6: Measuring range underflow channel 0
n Bit 7: Measuring range overflow channel 0
9
n Bit 0: Parametrization error channel 1
n Bit 1: 0 (fix)
n Bit 2: 0 (fix)
n Bit 3: 0 (fix)
n Bit 4: Wire break channel 1
n Bit 5: 0 (fix)
n Bit 6: Measuring range underflow channel 1
n Bit 7: Measuring range overflow channel 1
10
n Bit 0: Parametrization error channel 2
n Bit 1: 0 (fix)
n Bit 2: 0 (fix)
n Bit 3: 0 (fix)
n Bit 4: Wire break channel 2
n Bit 5: 0 (fix)
n Bit 6: Measuring range underflow channel 2
n Bit 7: Measuring range overflow channel 2
