RN
(RUN)
ST
(ST
OP)
SF
(SFAIL)
FC
(FRCE)
MC
(MMC)
Meaning
Firmware update
○ ● BB BB ● The alternate blinking indicates that there is new
firmware on the memory card.
○ ○ BB BB ● The alternate blinking indicates that a firmware
update is executed.
○ ● ● ● ● Firmware update finished without error.
○ BB* BB* BB* BB* * Blinking with 10Hz: Error during Firmware update.
on: ● | off: ○ | blinking (2Hz): BB | not relevant: X
LEDs Ethernet PG/OP channel L/A, S
The green L/A-LED (Link/Activity) indicates the physical connection of the Ethernet PG/OP channel to
Ethernet. Irregular flashing of the L/A-LED indicates communication of the Ethernet PG/OP channel via
Ethernet.
If the green S-LED (Speed) is on, the Ethernet PG/OP has a communication speed of 100MBit/s otherwise
10MBit/s.
Dependent on the mode of operation the LEDs show information
about the state of operation of the PROFIBUS part according to the
following pattern:
Master operation
RN
(RUN)
ER
(ERR)
DE IF Meaning
green red green red
○ ○ ○ ○ Master has no project, this means the interface is
deactivated respectively PtP is active.
● ○ ○ ○ Master has bus parameters and is in RUN without
slaves.
● ○ BB ○ Master is in "clear" state (safety state). The inputs of
the slaves may be read. The outputs are disabled.
● ○ ● ○ Master is in "operate" state, this means data exchange
between master and slaves. The outputs may be
accessed.
● ● ● ○ CPU is in RUN, at least 1 slave is missing.
● ● BB ○ CPU is in STOP, at least 1 slave is missing.
○ ○ ○ ● Initialization error at faulty parametrization.
○ ● ○ ● Waiting state for start command from CPU.
on: ● | off: ○ | blinking (2Hz): BB
LEDs PROFIBUS/PtP
interface X3
VIPA System 300S Hardware description
Structure > LEDs
HB140 | CPU | 314-6CF03 | GB | 16-43 37
