VIPA System 300S - Page 38

Slave operation
RN
(RUN)
ER
(ERR)
DE IF Meaning
green
red green red
○ ○ ○ ○ Slave has no project respectively PtP is active.
BB ○ ○ ○ Slave is without master.
BB* ○ BB* ○ * Alternate flashing at configuration faults.
● ○ ● ○ Slave exchanges data between master.
on: ● | off: ○ | blinking (2Hz): BB
