Vislink Microlite 3 User Manual

Operators Manual
Product Description
M55-ML3-UG, Rev A 12
Table 2: MLT3 Frequency Bands, Power and Power Consumption
Base Model Number
Frequency (GHz)
Power Out
(mW)
Power
Consumption
Watts
23MLT3-23
2.0 - 2.5
200
7
24MLT3-20
2.4-2.483
100
7
33MLT3-23
3.1 – 3.5
200
7
23/33MLT3-23
2.0-2.5/3.1-3.5
200
7
55MLT3-23
5.1- 6.0
200
7
23/55MLT3-23
2.0-2.5/5.1 – 6.0
200
7
64MLT3-20
6.4 - 7.1
100
13
5.3. Power Consumption
The MLT3 features extremely low power consumption. In addition, the MLT3’s hibernate
mode is specifically designed to save battery power when not being used. This mode lets
the MLT3 power down to all but the minimum required circuitry to listen for instructions.
Hibernate to full power takes less than 12 seconds.
5.4. Wi-Fi Controller
The MLT3 features a Wi-Fi transceiver for external status, control and configuration via
an iOS or Android device. Controls include:
• Transmitter status
• On/Off/Hibernate
• Product Information
• Channel, modulation and, Constellation Control
• Frequency Plan Update
• Optional 900 MHz Control
5.5. Transmitter Electrical Description
The transmitter is a two-board solution, with a simple aluminum chassis and external
connectors. It consists of two main boards:
• the encoder board
• modulator/RF board.
The encoder board handles all video input processing, digital pre-distortion, and
encoding. The FPGA, which in addition to the SDI block and digital pre-distortion, features
an embedded processor used for local encoder processing. The encoder is an H.264 HD
encoder.
