8.6.2. Manage Selected Transmitters
This section contains the remote-control commands for the dragonfly. It features two
main tabs:
1) RF Tab – Frequency and Power
2) Advanced Tab – all other parameters.
The following parameters may be controlled:
Table 8: Remote Control Applications Settings
Control
Activator
Description
Frequency
Text Box
Enter the frequency in Hz
Power
Buttons
Standby, Low or High-power buttons - push to activate
Modulation Type
Buttons
DVB-T or LMST - push to activate
Bandwidth
Buttons
Modulation type-dependent - push to activate
Constellation
Buttons
QPSK or 16QAM - push to activate
Code Rate
Drop Down
Modulation type-dependent - pick a value
Guard Interval
Drop Down
Modulation type-dependent - pick value (1/8 recommended
if the camera is moving)
Video Format
Drop Down
Choose camera format
8.6.3. Remote Control Action Keys
The 3
rd
section controls the actions of the VRC application:
1) ‘Apply to Selected’ button – sends new commands to the transmitters.
2) ‘Save Preset’ – Saves to a preset. The preset is given a name.
3) ‘Load Presets’ – Populates remote control commands with a predetermined parameter set.
4) Preset Tab
Store preset – may review stored presets.
