ELECTRICAL APPLIANCE CONTROL
D-307502 PowerMaster-10/30 G2 User's Guide 17
4. Electrical Appliance Control
Control Options and Pushbuttons
The system allows manual or automatic remote control of a device connected to the PGM output.
The user defines the ON and OFF times via the Scheduler (see Chapter 6 - B.14 Programming the Scheduler). The
installer determines which zone sensors will switch the remote controlled appliances on and off. However, the
decision whether the remote controlled appliance will respond as programmed is up to you (see next table).
Manual activation of a light or other household electrical appliance that is connected to PGM output.
Manual deactivation of a light or other household electrical appliance that is connected to PGM output.
Selecting the active automatic control method:
◼ Sensors: The appliance is controlled by sensors (assigned by the installer for this).
◼ Timer: The appliance is controlled by timer (ON and OFF times are defined by the installer).
◼ Both: The appliance is controlled by sensors as well as by a timer.
Examples of benefits gained by automatic remote control:
• Timer Control. When you are away, the timed activation / de-activation of an electrical appliance.
• Zone Control. Upon disturbance of a perimeter zone, the electrical device is switched on.
Notes:
1. Automatic activation and deactivation of electrical appliance depends also on the Scheduler setup (see
Chapter 6 - B.14 Programming the Scheduler).
2. PGM not to be enabled in UL Listed Product.
Automatic ON/OFF Control
You can select two of four options:
⚫ By Timer ON ⚫ By timer OFF
⚫ By sensor ON ⚫ By sensor OFF
The presently active options are shown with a dark box ( ) at the far right. To view the 2 other options click the
button.
A presently inactive option is shown without a dark box at the far right. The dark box will appear if you click
while the option is displayed. A “Success Tune” indicates successful saving of a new option.
