D-307502 PowerMaster-10/30 G2 User's Guide 73
E2. Wireless
PowerMaster-10 G2
PowerMaster-30 G2
RF Network
PowerG 2-way synchronized Frequency
Hopping (TDMA / FHSS)
PowerG 2-way synchronized Frequency
Hopping (TDMA / FHSS)
Frequency bands
(MHz)
433 434
868 - 869
912 919*
433 434
868 - 869
912 919*
Maximum Tx
Power
10 dBm @ 433 MHz, 14 dBm @ 868 MHz
Hopping
frequencies
8
4
50
8
4
50
Region
Worldwide
Europe
North
America and
selected
countries
Worldwide
Europe
North
America and
selected
countries
Encryption
AES-128
Note: AES-128 bit encryption for
communication between control unit and
initiating devices is not suitable as a means of
Encrypted Line Security in UL Listed product.
AES-128
Note: AES-128 bit encryption for
communication between control unit and
initiating devices is not suitable as a means of
Encrypted Line Security in UL Listed product.
Cellular Frequency
(MHz)
2G Band
3G Band
2G Band
3G Band
850, 900, 1800, 1900
850. 900, 1900, 2100
850, 900, 1800, 1900
850. 900, 1900, 2100
Note: The above frequencies are dependent
on country and operator.
Note: The above frequencies are dependent
on country and operator.
* For UL Listed product, enable this frequency band.
E3. Electrical
PowerMaster-10 G2
PowerMaster-30 G2
External AC/AC
adaptor
Europe: 230VAC 50Hz input, 9VAC 700mA
output.
USA: 120VAC 60Hz input, 9VAC 1000mA
output.
NA
External AC/DC
adaptor
NA
External (wall-mounted) switching power
supply 100VAC to 240VAC, 50/60 Hz, 0.5A /
12.5 VDC, 1.2A
Internal AC/DC
Internal switching power supply:
Input: 100-240VAC, 0.12 A Max.
Output: 7.5VDC, 1.2A Max.
Internal switching power supply:
Input: 100-240VAC, 0.75A
Output: 12.5 VDC, 1.6A.
Current Drain
Approx. 240 mA standby at the beginning
(power ON) and then goes down to 90 mA
standby, 1200 mA peak at full load.
The Plink module draws 200mA in quiescent
condition and 350mA during communication.
The cellular modem draws 25mA in quiescent
condition and 300mA during communication.
Note: When there is an AC fail, there are
three PLINK options: shutdown (PLINK is
turned off during AC failure), active 10 min.
(PLINK is turned off if AC failure duration is
longer than 10 minutes), or active (PLINK will
always be active).
Approx. 260 mA standby at the beginning
(power ON) and then goes down to 60 mA,,
1400 mA max. current drain during alarm.
Low Battery
Threshold
4.8 V
7.2 V (6-cell battery pack)
9.6 V (8-cell battery pack)
Backup Battery
Pack
4.8V 1300 mAh, rechargeable NiMH battery
pack, p/n GP130AAM4YMX, manufactured
by GP or p/n LTT-1300AA4Y, manufactured
by LTT.
4.8V 1800 mAh, rechargeable NiMH battery
pack, p/n GP180AAH4YMX, manufactured
by GP or p/n LTT-1800AA4Y, manufactured
by LTT.
4.8V 2200 mAh, rechargeable NiMH battery
pack, p/n GP220AAH4YMX, manufactured
Backup Battery Options:
Backup
period
Maximum external devices current (1)
1300 mAh
6 Battery
Pack (2)
1800 mAh
8-Battery
Pack (3)
2200 mAh
8-Battery
Pack (4)
4h
180 mA
300 mA
380 mA
8h
70 mA
125 mA
160 mA
12h
35 mA
70 mA
95 mA
24h
max
backup w/o
load 22
12 mA
25 mA
