72 D-307502 PowerMaster-10/30 G2 User's Guide
APPENDIX E. SPECIFICATIONS
E1. Functional
30 wireless zones (including 1 hard-wired
input).
Up to 64 wireless zones, (including 2 hard-
wired inputs).
Hard-wired Zone
Requirements
2.2 k E.O.L. resistance (max. resistance of
wires 220 )
2.2 k E.O.L. resistance (max. resistance of
wires 220 )
0.00 – 1.47 V (0.00 – 1.76 KΩ)
0.00 – 1.47 V (0.00 – 1.76KΩ)
1.47 – 1.80 V (1.76-2.64 KΩ)
1.47 – 1.80 V (1.76 – 2.64 KΩ)
1.80 – 2.03 V (2.64-3.52 KΩ)
1.80 – 2.03 V (2.64 – 3.52 KΩ)
2.03 – 2.33 V (3.52-5.26 KΩ)
2.03 – 2.33 V (3.52 – 5.26 KΩ)
2.33 – 3.30 V (5.26 - ∞ Ω)
2.33 – 3.30 V (5.26 – ∞ Ω)
• 1 master installer (9999 by default)*
• 1 installer (8888 by default)*
• 1 master user, no. 1 (1111 by default)
• Users nos. 2 - 8
* Codes must not be identical
• 1 master installer (9999 by default)*
• 1 installer (8888 by default)*
• 1 master user, no. 1 (1111 by default)
• Users nos. 2 - 48
* Codes must not be identical
-Integral keypad, wireless keyfobs and
keypads
- SMS commands via optional GSM/GPRS
module.
Remote control by telephone.
Note: For SIA CP-01 compliance, when using
KF-234 PG2 an external siren must also be
used. CP-01 features not to be enabled in UL
Listed product.
- Integral keypad, wireless keyfobs and
keypads
- SMS commands via optional GSM/GPRS
module.
- Remote control by telephone.
Note: For SIA CP-01 compliance, when using
KF-234 PG2 an external siren must also be
used. CP-01 features not to be enabled in UL
Listed product.
Single line, backlit 16-large character LCD.
Single line, backlit 16-large character LCD.
AWAY, HOME, AWAY-INSTANT, HOME-
INSTANT, LATCHKEY, FORCED, BYPASS.
Note: AWAY-INSTANT and HOME-INSTANT
are not permissible for CP-01 installations.
AWAY, HOME, AWAY-INSTANT, HOME-
INSTANT, LATCHKEY, FORCED, BYPASS.
Note: AWAY-INSTANT and HOME-INSTANT
are not permissible for CP-01 installations.
Silent, personal panic/emergency, burglary,
gas (CO), and fire .
Silent, personal panic/emergency, burglary,
gas (CO), and fire.
Continuous (intrusion / 24 hours / panic); triple
pulse – short pause - triple pulse... (fire);
four pulses – long pause – four pulses... (gas);
long pulse – long pause – long pulse... (flood).
Continuous (intrusion / 24 hours / panic); triple
pulse – short pause - triple pulse... (fire);
four pulses – long pause – four pulses... (gas);
long pulse – long pause – long pulse... (flood).
Programmable (4 min. by default)
Programmable (4 min. by default)
At least 85 dBA at 10 ft (3 m)
At least 85 dBA at 10 ft (3 m)
Programmable time frame for inactivity alert
Programmable time frame for inactivity alert
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over
Telephone, GSM /GPRS connections.
- Calling for help by using an emergency
transmitter.
- Tracking inactivity of elderly, physically
handicapped and infirm people.
Note: Tracking inactivity of elderly not to be
enabled in UL Listed product.
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over
Telephone, GSM /GPRS connections.
- Calling for help by using an emergency
transmitter.
- Tracking inactivity of elderly, physically
handicapped and infirm people.
- Message center (recording and playback)
- Two-way voice communication
Note: Tracking inactivity of elderly not to be
enabled in UL Listed product.
Alarm memory, trouble, event log
Alarm memory, trouble, event log
The control panel keeps and displays time and
date. This feature is also used for the log file by
providing the date and time of each event
The control panel keeps and displays time and
date. This feature is also used for the log file by
providing the date and time of each event
