Technical Reference Manual-XPM3m Revision Date: August 2014
CONTROL PANEL SYMBOLS
OPERATOR CONTROL STATION
 Use Caution
NOTICE
WHEN CONTROL POWER IS INTERUPTED, PARTS OF THE OVEN ARE ELECTRICALLY
POWERED AND DANGEREROUS TO PERSONNEL!
SELECTOR SWITCH
ADJUSTS RAIL
IN or OUT
KEY SWITCH RAISES
AND LOWERS THE
OVEN HOOD
