Technical Reference Manual-XPM3m Revision Date: August 2014
COMPUTER SYSTEM
The computer system must be set up and connected to the Vitronics Soltec Oven. The monitor and keyboard are
placed on the swing arm / light tower. The keyboard, monitor, and computer connect together. The connections on
the back of the computer are color coded, and they are different sizes/shapes to help connect them properly. (If the
keyboard/mouse does not function, swap the two connectors on the back of the Computer.)
One data cable must be connected from the computer to the oven.
Two 120VAC power cables (they are identical) are factory-wired for the Computer and Monitor. Plug the power
cables into the receptacles on the rear of the Computer and Monitor.
CONTROL CIRCUIT
Test procedure for safety interlock circuit
Activate all circuit breakers.
Ensure all E-stop switches are pulled out.
Log into the Oven control Program and reset the E-Stop Alarm
The E-stop relay K37 should be energized. If not, check the output of the control transformer using a Voltmeter
at wires #3 and #2. If voltage is present, but K37 is not energized, there is a break in the series connection of
safety interlocks.
Check that each E-stop and safety interlock switch de-energizes K37
Note: The enclosure safety interlock switches mentioned above are optional and do not exist on all ovens.
