3.3 Series
 For detailed information about the respective series:
See catalogs for High-performance universal joints (G830)
from Voith Turbo GmbH & Co. KG.
3.3.1 Type designations
The design of standard universal joint shafts can be read off using
t
he type designation. The design of special joint shafts must be
taken from the dimensional drawing.
Example R T 250.8 S 285/ S 315 R 2560
Series
S,R,CH,E
Center-section design
T,TL,TK,TR,F,GK,FZ,Z
Size. Bearing type
Flange design (S,K,Q,H)
S: friction flange
K: flange with split sleeve
Q: flange with face key
H: flange with Hirth connections
Flange size
input side/output side
Profile coating
S: Steel (Standard)
R: Rilsan
®
P: PTFE
Length l
min
or l
z min
in mm
