Voith CH Series - Tab. 6.1: Dimensions of the Connecting Flange and Bolted Connections (Key)

J.M. Voith SE & Co. KG/VTA | Instruction Manual
Installation
37
High
-performance universal joint shaft
Instruction manual (Translation)
G853 en 07/2013, Version1
Pos.
Description
Additional information (

Tab.
6
.
2
, page
40
)
v Length from the bearing
surface of the nut to the end
of the bolt
x face-key width
y
a
face-key depth
Z
1
Axial run-out Permissible values for deviation in axial runout Z
1
and
concentricity Z
2
at operating speeds < 1,500 min
-1
rpm ( column 10)
Halve values at higher speeds up to 3000 min
-1
.
Z
2
Radial run-out
Tab. 6.1: Dimensions of the connecting flange and bolted connections (key)
