Voith CH Series - Main overhaul; Life span of ATEX universal joint shafts

Maintenance
J.M. Voith SE & Co. KG /VTA| Instruction Manual
64
High
-performance universal joint shaft
Instruction manual (Translation)
G853 en 07/2013, Version1
RTL 550
RTK1 1500
RTK2 1500
590 – 620 CHT / ET 590
650 – 680 CHT / ET 700
710 CHT / ET 960
740 – 800 CHT / ET 1100
830 – 860 CHT / ET 1500
890 – 920 CHT / ET 2000
950 – 1010 CHT / ET 2400
1040 – 1200 CHT / ET 3700
1220 – 1340 CHT / ET 4900
Tab. 9.4: Permissible lubricant quantity for the re-lubrication of standard
center parts.
The lubricant quantities, which is spefified in Tab. 9.4, page 64
relate to the center part and have to be divded by the number of
lubricant nipples.
9.5 Main overhaul
Performing of the main overhaul requires specialized knowledge.
We recommend having the manufacturer's specialized personnel
perform the main overhaul.
 Please contact the manufacturer.
The screw plugs (6) are necessary for the overhaul of the universal
joint shaft.
 Do not loosen the screw plugs (6) ( Fig. 6.3, page 44).
9.6 Life span of ATEX universal joint shafts
ATEX-certified universal joint shafts must be sent back for main
ov
erhaul after expiration of the calculated life span ( see drawing
in the system documentation), at the longest after 5 years. The date
for the next main overhaul is on the nameplate (Chapter 3.1, page
22).
