Maintenance
63
High
-performance universal joint shaft
Instruction manual (Translation)
G853 en 07/2013, Version1
Rota [mm]
Standard designs
Amount of grease [cm³]
198 RT 170
208 RT 40
RTL 40
RTK1 80
RTK2 50
250 RT 60
RTL 70
RTK1 160
RTK2 110
285 RT 80
RTL 80
RTK1 250
RTK2 150
315 RT 90
RTL 100
RTK1 210
RTK2 150
350 RT 140
RTL 180
RTK1 690
RTK2 480
390 RT 150
RTL 190
RTK1 950
RTK2 580
440 RT 220
RTL 280
RTK1 740
RTK2 680
490 RT 340
RTL 430
RTK1 840
RTK2 770
550 RT 420
