3.3.4 CH Series
Size: 350–1460
Torque transmission: 260 - 19440 kNm
Flange design: Hirth serration or face-key
Area of application: rolling mill main drives, heavy machinery,
heavily-loaded drives in mechanical engineering
Type
Description
CHT Telescopic length with standard center part
CHF Fixed length universal joint shaft
CHGK Joint coupling; short, separable fixed length universal
joint shaft
3.3.5 E Series
Size: 590–1220
Torque transmission: 1600 - 14000 kNm
Flange design: 2-part flange yoke with coupling splines
arranged on an axis of symmetry, Hirth
serration on the flange
Area of application: rolling mill drives, heavy machinery
Type
Description
ET Telescopic length with standard center part
EF Fixed length universal joint shaft
EGK Joint coupling; short, separable fixed length universal
joint shaft
