VOLTCRAFT VC830 - Page 52

52
DC Current
Range Accuracy Resolution:
600 µA 0.1 µA
6000 µA
±(1.0% + 10)
1 µA
60 mA 0.01 mA
600 mA 0.1 mA
6 A
±(1.5% + 10)
0.001 A
10 A 0.01 A
Overload protection: Fuse, measuring time limit > 5 A: max. 10 s with 10 min break
Alternating current
Range Accuracy Resolution:
600 µA
±(1.3% + 5)
0,1 µA
6000 µA 1 µA
60 mA
±(1.6% + 8)
0.01 mA
600 mA 0.1 mA
6 A
±(2.0% + 8)
0.001 A
10 A 0.01 A
Overload protection: Fuse, measuring time limit > 5 A: max. 10 s with 10 min break
Frequency range 45 – 400 Hz; Overload protection 750 V
VC830: Effective average (RMS) at sinus voltage
VC850TrueRMS: Crest factor: max. 3.0 (at 750 V max. 1.5)
Resistance
Range Accuracy Resolution:
600 Ω ±(1.0% + 4) with REL function 0.1 Ω
6 kΩ 0.001 kΩ
60 kΩ ±(1.0% + 10) 0.01 kΩ
600 kΩ 0.1 kΩ
6 MΩ ±(1.5% + 10) 0.001 MΩ
60 MΩ ±(2.0% + 10) 0.01 MΩ
Overload protection 1,000V; Measuring voltage: Approx. 0.4 V
