51
Technical Data
Symbol 6000 counts
Measuring rate Approx. 3 measuring operations/second
measuring line length Approx. 90 cm each
Measuring impedance >10MΩ (V range)
Operating voltage 9V block battery
Working conditions 0 to 30°C (<75%rF), >30 to 40°C (<50%rF)
Operating altitude max. 2,000 m
Storage temperature -10°C to +50°C
Weight Approx. 380 g
Dimensions (LxWxH) 185 x 91 x 43 (mm)
Over-voltage category CAT III 1,000 V, CAT IV 600 V, contamination degree 2
Measurement tolerances
Statement of accuracy in ± (% of reading + display error in counts (= number of smallest points)).
The accuracy is valid for one year at a temperature of +23°C ± 5°C, and at a relative humidity of less than
75 %, non-condensing. Temperature coefficient: +0,1 x (specified accuracy)/1°C
Direct voltage
Range Accuracy Resolution
600 mV ±(0.5% + 8) 0.1 mV
6 V 0.001 V
60 V ±(0.6% + 8) 0.01 V
600 V 0.1 V
1,000 V ±(0.8% + 8) 1 V
Overload protection 1,000 V; Impedance: 10 MΩ
Alternating voltage
Range Accuracy Resolution
6 V 0.001 V
60 V ±(1.0% + 8) 0.01 V
600 V 0.1 V
750 V ±(1.3% + 5) 1 V
Frequency range 45 – 400 Hz; Overload protection 750 V
VC830: Effective average (RMS) at sinus voltage
VC850TrueRMS: Crest factor: max. 3.0
Permissible display error with an open measuring input: 2 counts
Permissible display error with a short-circuited measuring input: 20 counts
