13
Panels
2. DC 9V jack
Connect the separately sold AC adapter to this jack.
3. POWER switch
This switch turns the power on/o.
4. EXT.SW jack
This jack is used to connect the optional VOX VFS2
foot switch. The foot switch can control the following:
•
It can turn an eect on and o or select the eect type.
•
It can stop the operation of each loop or delete phrases.
5. INPUT SELECT switch
This switch changes according to the guitar or
microphone that is connected to the INPUT jack.
When changing the switch seings, make sure the
volume of the device connected to the OUTPUT
jack is set to 0.
6. INPUT jack
Connect your guitar or mic to this jack.
7. HEADPHONES jack
Connect headphones to this jack.
When headphones are connected to this jack, the
metronome sound will not be output from the
OUTPUT jack.
8. OUTPUT jack
Connect this jack to your guitar amp or mixer. The
output will be monaural.
