WABCO OptiTire - Page 47

47
Installation
Figure 4 Figure 5
Figure 6
In the case of steel rims the internal sensor sits
at on the rim.
Figure 7
In the case of aluminium rims only the rear
section of the wheel electronics sits on the rim.
Figure 8 Figure 9
Correcttoftheinternalsensor
Incorrecttoftheinternalsensor
