50
Installation
Installation
To better locate the sensor when mounted,
secure the sensor at the height of the valve
(Figure 7).
Figure 7
5. Secure the Velcro fastener by pulling the plastic strap loop centrally onto the sewn end of the
fastening strap (Figure 8).
Figure 8
Outside (marked)
6. Fit the tire according to Chapter "7.5 Assembly of the tire", page 51.
Ö The installation of the internal sensor SMS is completed.
