Drivetrain CT Repair
wc_tx000554gb.fm 110
8.13 Gearbox Assembly
See Graphic: wc_gr003367 and wc_gr003368
8.13.1 Install a new needle bearing (30) into the gearbox.
8.13.2 Press the roller bearing (29) onto the input shaft (19).
8.13.3 Press the roller bearing race into the gear box.
8.13.4 Install a new seal (32) and O-ring (90) into the side cover (7).
8.13.5 Add the spacer (35) to the input shaft assembly and install the input
shaft assembly into the gearbox. Also insert the spring (34).
8.13.6 Install a new seal (33) into the gearbox.
8.13.7 Install the retaining ring (87) onto the output shaft (20).
8.13.8 There is a recess (a) in the worm gear (18) in which the retaining ring
fits. Be sure to position the worm gear so that the recess faces the
short side of the output shaft. Install the key (86) and press the worm
gear onto the output shaft so that it fits tightly to the retaining ring.
8.13.9 Heat the two roller bearings (29) on a hot plate then install them onto
the output shaft. Press the bearings if necessary so that they fit tightly
to the worm gear.
8.13.10 Press the roller bearing race into the top cover. Also add O-ring (89)
and shims (91, 92) to the top cover. If the shims are damaged or worn,
replace them with the equivalent type and number of shims.
8.13.11 Position the output shaft assembly into the gearbox.
8.13.12 Before final installation, set the output shaft roller bearings. To do so,
install the top cover (6) and secure it with the screws (54). Torque the
screws to 25 Nm (18 ft.lbs.). Set the roller bearing by striking the output
shaft with a rubber mallet. You should be able to turn the output shaft
by hand and there should be virtually no end or side play.
8.13.13 Remove the top cover.
8.13.14 Install the input shaft. Rotate the input and output shafts as necessary
to align the gears.
8.13.15 Apply Loctite 243 or equivalent to screws (54) and install the side cover
(7). Torque the screws to 25 Nm (18 ft.lbs.). You should be able to turn
the input shaft by hand.
8.13.16 Apply Loctite 243 or equivalent screws (54) and reinstall the top cover.
Torque the screws
to 25 Nm (18 ft.lbs.).
8.13.17 Fill the gearbox with 620 ml (21 oz.) of Glygoyle 460 synthetic oil.
8.13.18 Install the brake cone (21) or pad (93).
8.13.19 Install the gearbox as described in section Replacing the Gearbox.
