CT 36 / CT 48
Technical Data
wc_td000141gb.fm
19
without handle
with handle
Model
Item No.
LxWxH
mm
(in.)
LxWxH
mm
(in.)
without
weight kit
kg (lbs.)
with
weight kit
kg (lbs.)
CT 36-5A
0009438
0620106
915x915x607
(36x36x24)
2005x915x1040
(79x36x41)
85 (183)
91 (201)
CT 36-6
0009443
915x915x607
(36x36x24)
2005x915x1040
(79x36x41)
85 (183)
91 (201)
CT 36-8A
0009439
915x915x686
(36x36x27)
2005x915x1040
(79x36x41)
94 (208)
103 (226)
CT 36-8A-V
0009442
915x915x686
(36x36x27)
2005x915x1040
(79x36x41)
94 (208)
103 (226)
CT 36-9
0009444
915x915x686
(36x36x27)
2005x915x1040
(79x36x41)
90 (199)
98 (217)
CT 36-9-V
0009447
915x915x686
(36x36x27)
2005x915x1040
(79x36x41)
90 (199)
98 (217)
CT 48-8A
0009449
1220x1220x686
(48x48x27)
2160x1220x1040
(85x48x41)
105 (234)
114 (252)
CT 48-9
0009453
1220x1220x686
(48x48x27)
2160x1220x1040
(85x48x41)
105 (234)
114 (252)
CT 48-11A
0009450
1220x1220x712
(48x48x28)
2160x1220x1040
(85x48x41)
113 (250)
122 (268)
CT 48-13A-V
0009452
1220x1220x712
(48x48x28)
2160x1220x1040
(85x48x41)
121 (268)
130 (286)
18
20
Table of Contents
Default Chapter
5
Table of Contents
5
1 Safety Information
8
Laws Pertaining to Spark Arrestors
8
Operating Safety
9
Operator Safety While Using Internal Combustion Engines
10
Service Safety
11
Label Locations
12
Safety and Information Labels
13
2 Technical Data
18
Dimensions and Weight
18
Engine
20
Trowel
24
Sound and Vibration Data
25
3 Operation
26
Application
26
New Machine Set-Up
26
Recommended Fuel
26
Installing Blades
27
Installing and Adjusting Handles
28
Controls
30
Stop Button
31
Before Starting
31
To Start - Honda
32
To Stop - Honda
33
To Start - Wacker
34
To Stop - Wacker
35
Engine Control Module
36
Operation
36
Braking System
38
Pitch Adjustment
39
4 Maintenance
40
Periodic Maintenance Schedule - Honda
40
Periodic Maintenance Schedule - Wacker
41
Engine Oil - Honda
42
Engine Oil - Wacker
43
Air Cleaner - Honda
44
Air Cleaner - Wacker
45
Spark Plug
46
Cleaning Sediment Cup - Honda
47
Cleaning Fuel Strainer - Wacker
47
Adjusting Idle Speed - Honda
48
Carburetor Adjustment - Honda
49
Belt Replacement
50
Trowel Lubrication
51
Optional Weights
51
Lifting
52
Storage
54
Troubleshooting
55
5 Guide Handle
56
Replacing the Throttle Cable
56
Adjusting the Throttle Lever
58
Upper Handle/Twist Pitch Control-Exploded View
60
Upper Handle/Twist Pitch Control-Components
61
Replacing the Upper Handle
62
Replacing the Twist Pitch Control Cable
64
Replacing the Lower Handle
66
Replacing the Stop Switch
67
6 Clutch
69
Replacing the Drive Belt
69
Drive Belt-Standard Clutch
70
Drive Belt-Variable Speed Clutch
71
Replacing the Standard Clutch
72
Standard Clutch-Exploded View
73
Standard Clutch Overhaul
74
Replacing the Variable Speed Clutch
76
7 Spider
78
Spider Assembly-Exploded View
78
Spider Assembly-Components
79
Replacing the Blades
80
Replacing the Arms
82
Balancing the Blade Pitch
84
Removing the Spider
86
Installing the Spider
88
Rebuilding the Lift Ring Assembly
90
8 Drivetrain
92
Drivetrain-Exploded View
92
Drivetrain-Components
93
Engine Removal
94
Engine Installation
96
Engine Wiring
98
Engine Wiring Components
99
Wiring Diagrams
100
Engine Wiring Components
101
Replacing the Gearbox
102
Gearbox-Exploded View
104
Gearbox-Components
105
Gearbox Disassembly
106
Gearbox Assembly
110
