WAGNER Cobra 40-10 Original Operating Manual

59
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
Order No. Designation
1 1 2329898 Sealing sleeve
2 4 9900204 Hexagon screw
3 4 9920102 Washer
4 2 341241 Inlet valve depressor, complete, see Chapter 14.10
5 1 2330764 Inlet housing
6 8 9907234 Hexagon screw
7 10 9920107 Washer
8 2 9974184 O-ring
9 2 322411 Valve tting
10 2 341336 Clasp
11 1 322914 Inlet valve set, complete (comprising 2 valves), see Chapter 14.9
13 1 2330810 Connection piece
14 1 322410 Fluid section
15 2 322412 Plug
16 2 9904311 Screw plug
17 1 169248 Relief valve, complete, see Chapter 14.11
18 1 322915 Outlet valve set, complete (spare parts for 2 valves)
19 1 2330775 Fitting, DF-MM-G3/8-G3/8-530 bar-SSt
20 1 322913 Complete diaphragm set with insert (comprising 2 diaphragms)
21 2 9904306 Screw plug
22 2 9970127 Sealing ring
23 1 2338520 Pressure stage D19/53
24 3 9907041 Hexagon screw
25 1 322402 Piston rod D19/53
26 2 9941502 Ball
27 2 9971189 O-ring
29 1 9962028 Permaglide bushing
30 1 322403 Pressure stage ange
31 2 9974182 Rod sealing prole BS
32 2 9974183 Rod sealing set
33 2 9974186 O-ring
34 2 9971446 O-ring
35 2 322405 Pressure disk
37 1 115944 O-ring
38 1 2352719 Oil tank set
40 1 9998274 Threaded plug G1/4
41 1 322435 Piston cover
42 1 2334842 Pressure relief valve
46 1 322404 Pressure stage cover disk
47 1 9974074 O-ring
49 4 9907233 Hexagon screw
50 4 9920102 Washer
51
1 2386160 Self-locking hexagon nut (new)
1 9910101 Hexagon nut, secured with Loctite® 243 (old version!)
53 2 322427 Damping washer
54 1 9974181 Piston sealing prole Z5
55 1 322426 Piston air motor 3
57 1 9974115 O-ring
59 2 9974185 Seal wiper ring, prole EM
60 1 2344068 Air motor ange
61 1 367258 Grounding, complete
62 1 369290 Pilot valve
63 1 9998675 Threaded plug
66 1 9998780 Pressure spring
67 2 322407 Oil valve screw
68 3 9971162 O-ring
