WAGNER Cobra 40-10 User Manual

Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
14 Spare Parts
Order number 2340851 | Edition 05/2022 71
Pos K Stk Order no. Designation
6 8 9907234 Hexagon screw
7 10 9920107 Washer
8 ♦ ⋆ 2 9974184 O-ring
9 2 322411 Valve fitting
10 2 341336 Clasp
11 ♦ ⋆ 1 322914 Inlet valve set, complete (comprising 2 valves), see Chapter Cobra
40-10 Inlet Valve [882]
13 1 2330810 Connection piece
14 1 322410 Fluid section
15 2 322412 Plug
16 2 9904311 Screw plug
17 ♦ 1 169248 Relief valve, complete, see Chapter Relief Valve [884]
18 ♦ ⋆ 1 322915 Outlet valve set, complete (spare parts for 2 valves)
19 1 2330775 Fitting, DF-MM-G3/8-G3/8-530 bar-SSt
20 ♦ ⋆ 1 322913 Complete diaphragm set with insert (comprising 2 diaphragms)
21 2 9904306 Screw plug
22 ♦ 2 9970127 Sealing ring
23 1 2338520 Pressure stage D19/53
24 3 9907041 Hexagon screw
25 1 322402 Piston rod D19/53
26 2 9941502 Ball
27 ♦ 2 9971189 O-ring
29 1 9962028 Permaglide bushing
30 1 322403 Pressure stage flange
31 ♦ 2 9974182 Rod sealing profile BS
32 ♦ 2 9974183 Rod sealing set
33 ♦ 2 9974186 O-ring
34 ♦ 2 9971446 O-ring
35 2 322405 Pressure disk
37 ♦ 1 115944 O-ring
38 1 2352719 Oil tank set
39 1 2339250 Oil suction fitting L=42
40 1 9998274 Threaded plug, G1/4
41 1 322435 Piston cover
42 1 2334842 Pressure relief valve
43 ♦ 1 9971162 O-ring
44 ♦ 1 115944 O-ring
46 1 322404 Pressure stage cover disk
47 ♦ 1 9974074 O-ring
49 4 9907233 Hexagon screw
50 4 9920102 Washer
51 1 2386160 Self-locking hexagon nut (new)
