Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
14 Spare Parts
72 Order number 2340851 | Edition 05/2022
Pos K Stk Order no. Designation
1 9910101 Hexagon nut, secured with Loctite ® 243 (old version!)
53 ♦ 2 322427 Damping washer
54 ♦ 1 9974181 Piston sealing profile Z5
55 1 322426 Piston air motor 3
57 ♦ 1 9974115 O-ring
59 ♦ 2 9974185 Seal wiper ring, profile EM
60 1 2344068 Air motor flange
61 1 367258 Grounding, complete
62 ♦ 1 369290 Pilot valve
63 1 9998675 Threaded plug
66 1 9998780 Pressure spring
67 2 322407 Oil valve screw
68 ♦ 3 9971162 O-ring
69 2 322415 Insert
70 ♦ 1 9974217 Rod seal
78 ♦ 4 341331 Sealing ring
89 ♦ ⋆ 2 9971486 O-ring (solvent-resistant)
90 ♦ 2 341316 Scraper
91 ♦ 1 9974112 Sealing ring for G3/8 thread
92 3 9920106 Washer
93 2 341325 Valve guide
94 2 341328 Clasp
95 ♦ 2 9971470 O-ring
96 2 341326 Pressure spring
97 2 253405 Spring support ring
98 ♦ 2 9941501 Ball 11 HM
99 ♦ 2 341327 Outlet valve seat
100 ♦ 2 341347 Sealing ring
101 1 9994237 Pressure spring
102 ♦ 2 322408 Oil valve pressure ring
103 1 9992590 Loctite ® 222 50 ml; 50 cc
104 1 9992831 Loctite ® 542 50 ml; 50 cc
105 ♦ ⋆ 1 9971395 O-ring, 10x1.25
106 1 2312288 Service set for Cobra 40-10 fluid section
107 1 322917 Service set for Cobra 40-10 piston (incl. items 25, 31, 32, 33, 59, and
108)
108 1 322930 Piston rod assembly pin
110 1 9992616 Molykote ® DX grease
111 1 9998808 Mobilux ® EP 2 grease
112 1 9992528 Loctite ® 270 50 ml; 50 cc
♦ = wearing parts
⋆ = Included in service set
