26
GM 5000EA
OPERATING MANUAL
EDITION 04/2016 ORDER NUMBER DOC2344499
5.4 TECHNICAL DATA
Maximum air pressure 0.8 MPa; 8 bar; 116 psi
Maximum product pressure 0.8 MPa; 8 bar; 116 psi
Fluid inlet NPSM 3/8"–18
Air connection NPSM 1/4"–18
Input voltage maximum 20 Vpp
Input current maximum 1.0 A AC
Output voltage maximum 70 kV DC
Output current maximum 100 µA DC
Ambient temperature 0 °C - 40 °C; 32 °F - 104 °F
Maximum permissible product temperature: 50 °C; 122 °F
Maximum surface temperature 85 °C; 185 °F
Compressed air quality: free from oil and water
Quality standard 6.5.2 according to ISO 8573.1, 2010
6: Particle density ≤ 5mg/m
5: Humidity: pressure dew point ≤ +7°C
2: Oil content ≤ 0.1mg/m
Weight (without hose set) 630 g (incl. union nut, nozzle and air cap)
Sound level at 0.3 MPa; 3 bar; 43.5 psi air pressure
and 0.3 MPa; 3 bar; 43.5 psi product pressure *
73 dB(A)
* A-rated sound pressure level measured at 1 m distance, LpA1m, in accordance with DIN EN 14462: 2005.
