41
GM 5000EA
OPERATING MANUAL
EDITION 04/2016 ORDER NUMBER DOC2344499
6.7 COMMISSIONING
The following points must be noted:
Make sure that all other conductive parts within the work area are grounded (see
Chapter 6.5.5).
Connect the product hose to the spray gun and the product pump or the pressure
tank.
Check that all product-conveying connections are correctly connected.
Connect air hose to spray gun and to supply of oil-free dry air, approx. 0.25 MPa; 2.5
bar; 36 psi. For compressed air quality see Chapter 5.4.
Check that all air-conveying connections are correctly connected.
Connect the electric cable to the spray gun and to the VM 5000 or VM 500 control
unit. See Chapter 6.7.3.1
Visually check the permissible pressures for all the system components.
When using a WAGNER pneumatic pump:
Check the level of the separating agent and ll the separating agent up if necessary.
Provide product tank, tanks for ushing agent and an empty tank for return ow.
Connect the system to the air and power supply.
A basic ushing of system must be carried out before commissioning. Make sure that
no nozzle is inserted into the gun.
6.7.1 SAFETY INSTRUCTIONS
Observe the safety instructions in Chapter 4 and Chapter 7.2.
Observe the general rules for making adjustments to the spray gun. Chapter 7.2.2
6.7.2 PREPARATION FOR COMMISSIONING
Impurities in the spraying system!
Clogging of the spray gun
Flush the spray gun and paint supply with a suitable ushing agent before
commissioning.
NOTICE
6.7.3 COMMISSIONING
