Order No. Designation
2310506 Air cap, AF 5000–0.4-0.8S
2310507 Air cap, AF 5000–1.0-1.4S
2310508 Air cap, AF 5000–1.6-2.0S
2314255 Air cap, AF 5000–0.4-0.8W (wide)
2314256 Air cap, AF 5000-1.0-1.4W (wide)
2314258 Air cap, AF 5000–1.6-2.0W (wide)
13.4 FLAT JET NOZZLES
13.4.1 AF 5000 AIR CAPS
13.3.3 NOZZLE SET EARV
Order No. Designation
Markings on union
nut
2361290
Nozzle set EARV 5000 LV
B_05984
suitable for low viscosity products
2365979
Nozzle set EARV 5000 HV
B_05985
suitable for high viscosity products
Mounting tool
353210 Air nozzle spanner
"?
Spare parts see Chapter 14.4.3.
