3
GM 5000EA
OPERATING MANUAL
EDITION 04/2016 ORDER NUMBER DOC2344499
Contents
1 ABOUT THESE INSTRUCTIONS 7
1.1 Preface 7
1.2 Warnings, Notices and Symbols in these Instructions 7
1.3 Languages 8
1.4 Abbreviations 8
1.5 Terminology for the Purpose of this Manual 9
2 CORRECT USE 10
2.1 Device Type 10
2.2 Type of Use 10
2.3 Use in an Explosion Hazard Area 10
2.4 Safety Parameters 10
2.5 Processible Working Materials 11
2.6 Reasonably Foreseeable Misuse 12
2.7 Residual Risks 12
3 IDENTIFICATION 13
3.1 Explosion Protection Identi cation FM 13
3.2 Type Plate 14
4 GENERAL SAFETY INSTRUCTIONS 15
4.1 Safety Instructions for the Operator 15
4.1.1 Electrical Equipment 15
4.1.2 Personnel Quali cations 15
4.1.3 Safe Work Environment 15
4.2 Safety Instructions for Sta 16
4.2.1 Safe Handling of WAGNER Spray Devices 16
4.2.2 Grounding the Device 17
4.2.3 Product Hoses 17
4.2.4 Cleaning and Flushing 18
4.2.5 Handling Hazardous Liquids, Varnishes and Paints 19
4.2.6 Touching Hot Surfaces 19
4.3 Protective and Monitoring Equipment 19
4.4 Use in Areas Subject to Explosion Hazards 20
4.4.1 Safety Regulations 20
4.5 Safety-Relevant Information about Discharges 20
5 DESCRIPTION 21
5.1 Structure (Standard Variant) 21
5.2 Mode of Operation 22
5.3 Scope of Delivery 24
5.3.1 Design Variants 25
5.4 Technical Data 26
5.5 Spraying Procedure 28
5.5.1 Spraying Procedure for Round Jet Air Atomizing 28
5.5.2 Spraying Procedure for Flat Jet Air Atomizing 29
5.5.3 Electrostatic E ect 30
5.6 The WAGNER Electrostatic Air Spraying System 31
5.6.1 Pressure Settings for Round Jet Nozzles 31
5.6.2 Pressure Settings for Flat Jet Nozzles 32
