WAGNER GM 5000EA - Page 95

95
GM 5000EA
OPERATING MANUAL
EDITION 04/2016 ORDER NUMBER DOC2344499
Spare parts list adapter
Order No. Designation
1 1 - Adapter GM 5000EA, complete
2
1 2309391 Air manifold ring, Air
3 1 2307180 O-ring, sheathed
4
1 2312179 Valve housing Air, complete (steel)
1 2312176 Valve housing Air, complete (PEEK)
5
1 2312184 Valve tip Air, complete (PEEK)
1 2312185 Valve tip Air, complete (steel)
6 1 2314271 Adapter GM 5000EA
7 1 2312181 Cascade, complete
8
1 9974166 O-ring
9 1 2307062 Clamping screw valve rod
10 1 2311562 Rod seal
11
1 2312177 Valve rod unit Air
12 1 2357106 Packing, complete
21 1 2307059 Withdrawal nut
22 1 9901411 Threaded pin with hexagon socket
24 1 2325263 Clamping screw assembly tool
25 1 2357665 Clamping screw valve rod, complete
1 2326335 Service set GA 5000EA
= Wearing part
= Included in service set
= Not part of the standard equipment but available as a special accessory.
