WAGNER PC 1025 PRO - Processible Coating Materials; Technical Data

30
PC 1025 PRO
EN
2.2 PROCESSIBLE COATING MATERIALS
PC 1025Pro can be used with a variety of materials, including
below:
• Stone Paint
• Putty (putty with sand, putty with bers)
• Thermal insulation composite system bonding agent
(mineral and artstoneicial resin systems)
• Articial resin plasters
• Silicate plasters
• Silicone resin plasters
• Mineral nal coats
• Lightweight plaster systems
• Scraped stucco
• Thermal insulation plasters
• Restoration plaster
• Porous concrete coating
• Quartz plastic
• Roof coatings
• Fire protection coatings
• Mineral sealing sludges
• Bitumen emulsions
• Armoring ller
• Liquid wood-chip wall paper
• Casement grouting mortar
• Articial resin rendering base
• Wash primer
• Filling paint, also brous
• Elastic coating
• Acoustic plaster, articial resin bonded
• Fillers, articial resin bonded
Remark:
• The maximum allowable grain size is 6 mm
• All the coating materials must be suitable for machine pro-
cessing. Refer to the product data sheet of the coating ma-
terial to be processed or contact your authorized Wagner
dealer or the Wagner hotline at 400-6118-808.
3 TECHNICAL DATA
PC 1025Pro
Voltage: 230 V~, 50/60 Hz
Fusing: 16 A time-lag
Device supply cable: 5 m long, 3 x 2.5 mm
2
Motor output P
1
: 2.3 kW
Max. convey capacity (water): 10, 15, 20 l/min
(depending on the rotor/
stator)
Max. operating pressure: 40 bar
Max. granular size: 6 mm
Dimensions L x W x H: 1150 x 520 x 610 mm
Container capacity: 50 l
Weight (PC 1025Pro): 59 kg
Weight (Spray lance): 1.0 kg
Max. tyre pressure: 2.0 bar
Degree of protection: IP 54
Max. sound pressure level: 70 dB (A)*
Atomizing air connection: Rapid action coupling
DN 7.2 mm
Max. atomizing air pressure: 10 bar
Minimum required compressed
air volume: 320 l/min
Max. mortar hose length: 40 m (and 2.5 m hose
whip)
Max. delivery height: 20 m
* Place of measurement: 1 m distance from unit and 1.60 m
above reverberant oor.
