WAGNER PC 1025 PRO - Compressor (Accessory); Mortar Hose; Spray Lance

33
PC 1025 PRO
EN
4.3 COMPRESSOR ACCESSORY
VKM 592 intake volume 590 l/min
Note:
Only operate the compressor in accordance with the enclosed
operating manual.
OVERVIEW
4.4 MORTAR HOSE
1 Material connection mortar spraying machine
2 Atomizing air connection compressed air supply
3 Material connection spray lance
4 Mortar hose
5 Atomizing air connection spray lance
4.5 SPRAY LANCE
1 Material connection
2 Material tap:
Open: material tap points backwards
Closed: material tap at 90° to spray lance
3 Texture tip:
Various texture tips can be used in the spray lance. The tip
size depends on the granular size of the coating material
and the desired spray pattern.
4 Air ow regulator (switches the machine on and o)
5 Atomization air connection
C330 intake volume 330 l/min
Note:
Only operate the compressor in accordance with the enclosed
operating manual.
1
2
3
4
5
2
1
5 4
3
