WAGNER PC 1025 PRO - Spare Parts List Frame; Spare Parts List of Spray Lance

46
PC 1025 PRO
EN
SPARE PARTS LIST OF SPRAY LANCE
12 SPARE PARTS LIST  SPRAY LANCE
ITEM PART NO. DESIGNATION
2438 213 Spray lance
1 2416 818 Union nut
2 2416 819 Sealing washer
3 2416 609 Texture tip 6 (standard)
11.1 SPARE PARTS LIST FRAME
1
2
3
4
ITEM
ORDER NO.
DESIGNATION
1 2416991 Carriage
2 3142039 Ring nut M12
3 2416816 Guide pulley
4 2416631 Wheel
1
2
3
