WAGNER PEM-X1 CG User Manual

18
VERSION 05/2019
ORDER NUMBER DOC2326960
PEM-X1 CG
4.3 INFORMATION ABOUT SAFE DISCHARGES
P_03884
1
2
3
4
Designation
1 Nozzle
2 Electrode
3 Luminous discharge
4 Work piece
With the high voltage switched on, a luminous or corona discharge occurs at the electrode
tip; this can only be seen in the dark. This physical eect can be seen when the electrode
is brought near the grounded work piece. This luminous discharge does not involve any
ignition energy and has no eect on system handling. When the electrode approaches the
work piece, the control unit automatically reduces the high voltage to a safe value. If you
touch plastic parts of the spray gun with your nger, harmless discharges may occur due to
the high-voltage eld around the spray gun (so-called brush discharges). However, these
do not contain any ignition energy.
