N 05/2019
ORDER NUMBER DOC
232
69
60
PEM-
X1 C
G
6.4.4
HOW
TO USE
THE POWDER CUP
Cov
er 1 is only needed on the gun if the gun is angled
such that powder escapes fr
om the tank.
P_01730
3
2
1
During coating, the ip-op latch 2 must be open.
It is opened by pulling up the toggle.
F
or storage purposes, the tank must be closed by
tting cover 1, closing ip op la
tch 2 and attaching
small cover 3 a
t the bottom of the tank.
24
26
