29
VERSION 05/2019
ORDER NUMBER DOC2326960
PEM-X1 CG
2 Illuminated display: "Corona or Tribo Current"
Lights up green
Tribo scale:
When a Tribo gun is connected and selected
Bar display: When powder feed is activated
Display range: 0–5 µA
Resolution 0.5 µA
Corona scale:
When a Corona gun is connected and selected
Display and adjusting range: 0 [5]–120 µA,
0 [5]–20 µA resolution 5 µA
20-40 µA resolution 10 µA
40-120 µA resolution 20 µA
Single LED display: "Trigger Point of Current Limitation"
Bar display: Corona current
3 Display: "Tribo Gun"
Lights up when a Tribo gun is connected and selected
4 Display: "Corona Gun"
Lights up when a Corona gun is connected and selected
5 Push button: recipe for "Surface parts"
6 Push button: recipe for "Second coating"
7 Push button: recipe for "Proles"
8 Push button: recipe for "Double click"
To access the recipe, press the trigger lever on the spray gun twice in quick
succession and hold it down
9 LED display: recipe for "Surface parts"
Lights up green when the recipe for surface part is selected
10 LED display: recipe for "Second coating"
Lights up green when the recipe for "Second coating" is selected
11 LED display: recipe for "Proles"
Lights up green when the recipe for prole part is selected
12 LED display: recipe for "Double click"
Lights up green, when the recipe for "Double click" is selected
13 LED display: "Fault"
Lights up, when there is a fault on the device
