Page #32 background imageLoading...
Page #32 background image
32
VERSION 05/2019
ORDER NUMBER DOC2326960
PEM-X1 CG
33 Illuminated display: "Powder quantity"
Lights up green
Display range: 0–100%
Resolution: 3.33%
Single LED display: Set point (high voltage and powder are deactivated)
Bar display: Actual value (high voltage and powder are activated)
34 Illuminated display: "Total air volume"
Lights up green
Display range: 2–6 m³/h
Resolution: 0.2–0.5 m³/h
Single LED display: Set point (high voltage and powder are deactivated)
Bar display: Actual value (high voltage and powder are activated)
35 Illuminated display: "Atomizing, ionizing and Tribo air volume"
Lights up green
Display range: 0.1–4 m³/h
Resolution: 0.1–1.0 m³/h
Single LED display: Set point (high voltage and powder are deactivated)
Bar display: Actual value (high voltage and powder are activated)
36 Push button: "Powder quantity"
To activate the function, the powder quantity is set with control dial 24 and is
indicated in LED display 19.
Adjusting range: 1–100%
Resolution: 1%
37 LED display: "Powder quantity"
Lights up yellow, when the powder quantity is selected
