4
VERSION 05/2019
ORDER NUMBER DOC2326960
PEM-X1 CG
6.4 Preparing the Cup Gun 22
6.4.1 Selection of a Suitable Nozzle System 22
6.4.2 Powder Cup 24
6.4.3 Assembling the Powder Cup 24
6.4.4 How to Use the Powder Cup 25
6.5 Connecting the Manual Gun 26
6.6 Grounding 26
6.6.1 Grounding the Powder Coating System 27
6.7 Safety Checks 27
7 OPERATION 28
7.1 Training the Operating Personnel 28
7.2 Tasks 28
7.3 Operation of the Control Unit 28
7.4 Optimizing the Powder Cloud for Coating 33
7.4.1 Recommended Settings for Total Air Volume 33
7.5 Switching O the Cup Gun 33
7.5.1 Pressure Relief/Work Interruption 33
7.6 "Double Click" Program (High Dynamic Remote) 34
7.7 Reproducible Setting of the Nozzle Position 35
8 CLEANING AND MAINTENANCE 36
8.1 Cleaning 36
8.1.1 Cleaning Personnel 36
8.1.2 Cleaning Procedures 36
8.2 Maintenance 36
8.2.1 Maintenance Personnel 36
8.2.2 Maintenance Instructions 37
8.2.3 Safety Checks and Maintenance Intervals 37
8.2.4 Maintenance Procedures 37
8.3 Exchanging the Manual Gun 38
8.4 Changing the Flat Jet Nozzle 39
8.4.1 Removing the Flat Jet Nozzle 39
8.4.2 Fitting the Flat Jet Nozzle 40
8.5 Changing the Round Jet Nozzle 41
8.5.1 Removing the Round Jet Nozzle 41
8.5.2 Fitting the Round Jet Nozzle 42
8.6 Replacing the Protective Wedge 43
8.6.1 Removing the Protective Wedge 43
8.6.2 Installing the Protective Wedge 44
8.7 Changing from Flat Jet Nozzle to Round Jet Nozzle 45
8.8 Assembly of the CoronaStar 47
8.9 Replacing the Suspension Hook 48
8.10 Replacing the Collector Nozzle 49
8.11 Replacing the Connecting Tube 50
9 TROUBLESHOOTING AND RECTIFICATION 51
10 INSPECTIONS 52
11 DISASSEMBLY AND DISPOSAL 54
11.1 Disassembly 54
11.2 Disposal 54
