PEM-X1
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC 2326020
Table of Contents
7 OPERATION 28
7.1 Training the Operating Sta 28
7.2 Safety Instructions 28
7.3 Optimizing the Powder Cloud for Your Coating 29
7.3.1 Recommended Settings for Total Air Volume 29
7.4 Switching O the Spray Gun 30
7.5 Adjustment of Powder Quantity 31
7.6 "Double Click" Program (High Dynamic Remote) 32
7.7 Reproducible Setting of the Nozzle Position 33
8 CLEANING AND MAINTENANCE 34
8.1 Cleaning 34
8.1.1 Cleaning Sta 34
8.1.2 Safety Instructions 34
8.1.3 Cleaning Procedures 35
8.2 Maintenance 36
8.2.1 Maintenance Sta 36
8.2.2 Safety Instructions 36
8.2.3 Maintenance Procedures 37
8.2.4 Replacing the Spray Gun 38
8.3 Removing the Fan spray nozzle 39
8.4 Fitting the Fan spray nozzle 40
8.5 Removing the Round spray nozzle 41
8.6 Fitting the Round spray nozzle 42
8.7 Replacing the Protective Wedge 43
8.8 Changing from Fan spray nozzle to Round spray nozzle 45
8.9 Assembly of the CoronaStar 47
8.10 Replacing the Suspension Hook 48
9 INSPECTIONS IN ACCORDANCE WITH DIN EN 500502: 2014 49
9.1 Overview of Inspections 50
10 DISASSEMBLY AND DISPOSAL 51
10.1 Disassembly 51
10.2 Disposal 51
11 TROUBLESHOOTING AND RECTIFICATION 52
12 ACCESSORIES 54
12.1 Fan spray nozzle 54
12.2 De ector Cone 54
12.3 Electrode Holder 54
12.4 Hose Take-up 55
12.5 CoronaStar Retro t Set 55
12.6 Wedge Tool 55
12.7 Nozzle Extension, X1 VL 150/300/500 56
12.8 Nozzle Extension, X1 VL 750 56
12.9 Powder Hose 57
12.10 Gun Connection Cable 57
12.11 Wall Mount 57
12.12 Recipe Sticker 58
12.13 Powder Measuring Adapter 59
